Name: StarTech.com 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Ethernet Interface - Supports Windows, Linux, VMware ESXI (PR12GIP-NETWORK-CARD) - Network adapter - P
Brand: StarTech.com
SKU: 1TNETNHS-067719
Price: 108.91 GBP
Availability: InStock

Overview

Main features

StarTech.com 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Ethernet Interface
Supports Windows, Linux, VMware ESXI (PR12GIP-NETWORK-CARD)
Network adapter
PCIe 2.0 low profile
2.5GBase-T (PoE+) x 1
black

Overview

This 2.5 GbE network interface card (NIC) features an Intel I225-V chipset with Intel vPro technology, to enhance performance and data integrity. The variable multispeed options (2.5/1Gbps and 100/10Mbps) enable support for both new and legacy network hardware. Utilize existing Cat5e or CAT6 cabling infrastructure while adding NBASE-T (802.3bz) compatibility for seamless integration.

Specification

Product Description StarTech.com 1-Port 2.5Gbps NBASE-T PoE Network Card, Intel I225-V, 802.3af/at PoE+ Multi-Gigabit NIC, PCI Express Server LAN Card, SATA Powered Desktop Ethernet Interface - Supports Windows, Linux, VMware ESXI (PR12GIP-NETWORK-CARD) - network adapter - PCIe 2.0 - 2.5GBase-T (PoE+) x 1

Device Type Network adapter

Form Factor Plug-in card - low profile

Interface (Bus) Type PCI Express 2.0 x1

PCI Specification Revision PCIe 2.0

Ports 2.5GBase-T (PoE+) x 1

Dimensions (WxDxH) 1.6 cm x 11.9 cm x 5.4 cm

Weight 62 g

Cabling Type Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T

Data Link Protocol 10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE

Data Transfer Rate 2.5 Gbps

Capacity Jumbo frame size: 9000

Processor Intel I225-V

Compliant Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1as, IEEE 802.1x, IEEE P802.3az, IEEE 1588v1

Colour Black

System Requirements Microsoft Windows 10 / 11, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Linux 5.8.x or later (LTS versions only), VMware ESXi 7.0

Manufacturer Warranty 2-year warranty

General

Device Type Network adapter

Form Factor Plug-in card - low profile

Interface (Bus) Type PCI Express 2.0 x1

PCI Specification Revision PCIe 2.0

Networking

Ports 2.5GBase-T (PoE+) x 1

Connectivity Technology Wired

Cabling Type Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T

Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet

Data Transfer Rate 2.5 Gbps

Capacity Jumbo frame size: 9000

Status Indicators Link/activity/speed

Features Intel vPro Technology support, PSE, PXE boot, WOL, VLAN support, full duplex capability, auto-negotiation, Auto MDIX, bus powered, QoS, PTP, EEE

Compliant Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1as, IEEE 802.1x, IEEE P802.3az, IEEE 1588v1

Processor / Memory

Processor Intel I225-V

Expansion / Connectivity

Interfaces 2 x 2.5 GBase-T (PoE+) - RJ-45

Miscellaneous

Included Accessories Low-profile bracket

Compliant Standards RoHS, WEEE

Colour Black

Software / System Requirements

OS Required Microsoft Windows 10 / 11, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Linux 5.8.x or later (LTS versions only), VMware ESXi 7.0

Dimensions & Weight

Width 1.6 cm

Depth 11.9 cm

Height 5.4 cm

Weight 62 g

Dimensions & Weight (Shipping)

Shipping Width 3 cm

Shipping Depth 17 cm

Shipping Height 14 cm

Shipping Weight 70 g

Manufacturer Warranty

Service & Support Limited warranty - 2 years
