The MPG series brings out fashionable products by showing extremely unique styles and expressing a conceited attitude towards the challenge of the gaming world. With extraordinary performance and style, the MPG series defines the future of gaming fashion.
Device TypePower supply - active Power Factor Correction (PFC) - internal
Specification ComplianceATX12V / EPS12V
80 PLUS Certification80 PLUS Gold
Weight3.45 kg
Input VoltageAC 100-240 V
Output Voltage+3.3, +5, ±12 V
Power Capacity1000 Watt
Output Current+3.3V - 22 A ¦ +5V - 22 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A ¦ +12V - 83.5 A
Output connectors1 x power 24 pin ATX ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 12+4 pin PCI Express 5.0 power ¦ 6 x 8 pin PCI Express power with detachable 2 pin section ¦ 12 x 15 pin Serial ATA power ¦ 5 x 4 PIN internal power
Modular Cable ManagementYes
Cooling System120 mm fan
Included AccessoriesScrews
Dimensions (WxDxH)15 cm x 15 cm x 8.6 cm
Manufacturer Warranty10 years warranty
Extended Specification
General
Device TypePower supply - active Power Factor Correction (PFC) - internal
Specification ComplianceATX12V / EPS12V
PSU Form FactorATX
Power Device
Input VoltageAC 100-240 V
Frequency Required50 - 60 Hz
Power Output Connectors Details1 x power 24 pin ATX ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 12+4 pin PCI Express 5.0 power ¦ 6 x 8 pin PCI Express power with detachable 2 pin section ¦ 12 x 15 pin Serial ATA power ¦ 5 x 4 PIN internal power
Output Voltage+3.3, +5, ±12 V
Power Capacity1000 Watt
Output Current+3.3V - 22 A ¦ +5V - 22 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A ¦ +12V - 83.5 A
Efficiency90%
Modular Cable ManagementYes
80 PLUS Certification80 PLUS Gold
Miscellaneous
Included AccessoriesScrews
Cables IncludedATX power cable 60 cm ¦ 16-pin 12VHPWR power cable 60 cm ¦ 16-pin 12VHPWR to 2x8 pin PCI Express power adapter 60 cm ¦ 2 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable 60 cm ¦ 2 x power 8 pin +12V with detachable 4 pin section modular cable 70 cm ¦ 3 x power 15 pin SATA cable ¦ 4 pin internal power cable ¦ AC input cable - external
Cooling System120 mm fan
FeaturesOverpower protection, over voltage protection, short-circuit protection, undervoltage protection, over current protection, overheat protection, fully modular, fluid dynamic bearing cooling fan, LLC Half Bridge Topology, DC-DC technology, single 12V rail, Zero RPM fan mode
