Main features

LG 55UL3J-M
55" Diagonal Class UL3J Series LED-backlit LCD display
digital signage with Integrated Pro:Idiom
webOS
4K UHD (2160p) 3840 x 2160
Direct LED
ash blue

Overview

LG 55UL3J-M UL3J Series - 55" with Integrated Pro:Idiom LED-backlit LCD display - 4K - for digital signage

Product Description LG 55UL3J-M UL3J Series - 55" with Integrated Pro:Idiom LED-backlit LCD display - 4K - for digital signage

Product Type LED-backlit LCD flat panel display with Integrated Pro:Idiom

Diagonal Class 55"

Commercial Use Yes - digital signage

Colour Ash blue

Platform webOS 6.0

Resolution 3840 x 2160

Display Format 4K UHD (2160p)

Frame Rate & Enhancement Technology 60 Hz Refresh Rate

Video Interface HDMI

HDMI Ports Qty 3 ports

Connectivity Wi-Fi, LAN

Technology ADS

LCD Backlight Technology Direct LED

Image Aspect Ratio 16:9

TV Tuner No tuner

Commercial Features SNMP support, No Signal image, Sync Mode, Integrated Contents Management System (CMS), SuperSign CMS compatible, SuperSign Control+ compatible, Real Time Communication (webRTC), Local Key Operation, FailOver, SuperSign WB compatible, LG ConnectedCare, LG One:Quick Share compatible, Video Tag, booting logo image, Auto Set ID, play via URL, ISM Method

Settings Cloning Capability Yes

Picture Enhancements DCI 80% Colour Gamut

Storage Capacity 16GB eMMC

USB 2 ports

Included Accessories Remote control, cable holder

Voltage AC 100-240 V (50/60 Hz)

Energy Class Class G

Power Consumption Operational 105 Watt

Power Consumption Stand by 0.5 Watt

Dimensions (WxDxH) - without stand 123.5 cm x 5.75 cm x 71.5 cm

Weight 14 kg

Environmental Standards ENERGY STAR Qualified, EPEAT Bronze

General

Product Type LED-backlit LCD flat panel display with Integrated Pro:Idiom

Energy Class Class G

Power Consumption (Max) 160 Watt

Power Consumption Operational 105 Watt

Power Consumption SDR (On mode) 102 kWh/1000h

Diagonal Class 55"

Commercial Use Yes - digital signage

Series UL3J Series

Platform webOS 6.0

Operating System webOS 6.0

TV Tuner No tuner

TV Tuner Presence No

Sensors Temperature sensor, brightness sensor

Video Interface HDMI

HDMI Ports Qty 3 ports

Modes Portrait mode, landscape mode, Tile Mode, PM mode

Picture Enhancements DCI 80% Colour Gamut

Design Slim Design

Dimensions Without stand

Width 123.5 cm

Depth 5.75 cm

Height 71.5 cm

Weight 14 kg

Enclosure Colour Ash blue

Display

LCD Display Technology ADS

Resolution 3840 x 2160

Display Format 4K UHD (2160p)

Image Aspect Ratio 16:9

Frame Rate & Enhancement Technology 60 Hz Refresh Rate

LCD Backlight Technology Direct LED

Coating 1% haze

Image Contrast Ratio 1200:1

Dynamic Contrast Ratio 1000000:1

Brightness 400 cd/m²

Viewing Angle 178 degrees

Viewing Angle (Vertical) 178 degrees

Response Time 8 ms

Backlight Life 30,000 hour(s)

Commercial Features SNMP support, No Signal image, Sync Mode, Integrated Contents Management System (CMS), SuperSign CMS compatible, SuperSign Control+ compatible, Real Time Communication (webRTC), Local Key Operation, FailOver, SuperSign WB compatible, LG ConnectedCare, LG One:Quick Share compatible, Video Tag, booting logo image, Auto Set ID, play via URL, ISM Method

Settings Cloning Capability Yes

Operation Hours / Days 16 / 7

Features Crestron Connected Compatible, BEACON technology, wireless access point, Cisco Certified, 1.07 billion colours (8-bit+FRC)

Stands & Mounts

Flat Panel Mount Interface 300 x 300 mm

VESA Compatibility Yes

Media Player

USB Port Yes

USB Ports Qty 2

Configuration 16GB eMMC

Remote Control

Type Remote control

Battery Included Yes

Battery Included Qty 2

Battery Required Qty 2

Audio System

Features Built-in speaker

Network & Internet Multimedia

Connectivity Wi-Fi, LAN

LAN Protocol Ethernet

Connect & Share Screen Share

Connections

Connector Type 3 x HDMI input ¦ 2 x USB 2.0 ¦ Audio output ¦ RS-232C input ¦ RS-232C output ¦ LAN

Miscellaneous

Included Accessories Cable holder

Compliant Standards Plug and Play, FCC Class A certified, CB, EMC, ERP, NRTL, HDCP 2.2, HDCP 1.4

Sustainability Information

EPEAT Compliant EPEAT Bronze

ENERGY STAR Certified Yes

Power

Power Device Power supply

Input Voltage AC 100-240 V (50/60 Hz)

Power Consumption Stand by 0.5 Watt

Power Consumption (Off Mode) 0.5 Watt

Heat Generation Details Cabinet - typical - 358 BTU/h ¦ Cabinet - max - 546 BTU/h

Features Smart energy saving, WOL (Wake on LAN)

Dimensions & Weight (Shipping)

Width (Shipping) 136 cm

Depth (Shipping) 16.2 cm

Height (Shipping) 81 cm

Weight (Shipping) 18.8 kg

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Humidity Range Operating 10 - 80%
