Intel Next Unit of Computing 12 Pro Kit - NUC12WSKv7 - Barebone - tall chassis - 1 x Core i7 1270P - vPro Enterprise - RAM 0 GB - Intel Iris Xe Graphics - GigE, 2.5 GigE, Bluetooth 5.2 - WLAN: 802.11a/b/g/n/ac/ax, Bluetooth 5.2
Manufacture#: RNUC12WSKV70000
Order by 15:00 and receive your order on Monday 17 Mar
Product details
NUC12WSKv7
Barebone
tall chassis
1 x Core i7 1270P
Payment options available at checkout
Main features
Intel Next Unit of Computing 12 Pro Kit
NUC12WSKv7
Barebone
tall chassis
1 x Core i7 1270P
vPro Enterprise
RAM 0 GB
Intel Iris Xe Graphics
Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.2 WLAN:
802.11a/b/g/n/ac/ax, Bluetooth 5.2
Overview
The Intel NUC kit features a customizable board and chassis that are ready to accept a wide variety of memory, storage, and operating systems. For businesses, students, educators, gamers and DIYers.
Product Description
Intel Next Unit of Computing 12 Pro Kit - NUC12WSKv7 - tall chassis - Core i7 1270P - vPro Enterprise - 0 GB - no HDD
Type
PC barebone - tall chassis
Platform Technology
Intel vPro Enterprise
Processor
1 x Intel Core i7 (12th Gen) 1270P (up to 4.8 GHz, (12-core)
Processor Main Features
Intel Virtualization Technology, Intel Trusted Execution Technology, Intel AES New Instructions, Intel Virtualization Technology for Directed I/O, Intel Platform Trust Technology (PTT), Intel vPro Platform Eligibility
Cache Memory
18 MB
Cache Per Processor
18 MB
RAM
0 GB (installed) / 64 GB (max) - DDR4 SDRAM
Storage Controller
SATA/NVMe (SATA 6Gb/s / PCIe 4.0 x4 (NVMe))
Hard Drive
No HDD
Optical Storage
No optical drive
Graphics Controller
Thunderbolt 4 / HDMI - Intel Iris Xe Graphics
Audio Output
7.1 channel surround
Networking
1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, 2.5GbE, 802.11ax, Bluetooth 5.2
Software Included
Intel Management Engine Firmware 16
Dimensions (WxDxH)
11.7 cm x 11.2 cm x 5.4 cm
Manufacturer Warranty
Limited warranty - 3 years
General
Platform Technology
Intel vPro Enterprise
Type
PC barebone
Product Form Factor
Tall chassis
Processor / Chipset
CPU
Intel Core i7 (12th Gen) 1270P
Max Turbo Speed
4.8 GHz
Number of Cores
12-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Not upgradable
Processor Main Features
Intel Virtualization Technology, Intel Trusted Execution Technology, Intel AES New Instructions, Intel Virtualization Technology for Directed I/O, Intel Platform Trust Technology (PTT), Intel vPro Platform Eligibility
Cache Memory
Installed Size
18 MB
Cache Per Processor
18 MB
RAM
Installed Size
0 GB / 64 GB (max)
Technology
DDR4 SDRAM
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 2 (empty)
Features
Dual channel memory architecture
Storage Controller
Type
SATA/NVMe
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
Thunderbolt 4 / HDMI
Graphics Processor
Intel Iris Xe Graphics
Video Interfaces
HDMI, USB-C
Max Monitors Supported
4
Audio Output
Sound Output Mode
7.1 channel surround
Compliant Standards
High Definition Audio
Networking
Ethernet Ports
2.5 Gigabit Ethernet
Ethernet Controller
Intel I225-V
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, 802.11ax, Bluetooth 5.2
Expansion / Connectivity
Slots
1 (total) / 1 (free) x M.2 Card - 2280 (Key M) ¦ 1 (total) / 1 (free) x M.2 Card - 2242 (Key B) ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (Key E)
Interfaces
2 x Thunderbolt 4/USB4/DisplayPort 1.4 - Type C ¦ 3 x USB 3.2 Gen 2 - Type A (2 front, 1 rear) ¦ 2 x USB 2.0 - header (2 internal) ¦ 1 x USB 2.0 - Type A (1 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) - RJ-45 ¦ 2 x HDMI ¦ 1 x headphones/microphone - stereo mini-jack
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
CEC
Power
Device Type
No power supply
Operating System / Software
Software
Intel Management Engine Firmware 16
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Width
11.7 cm
Depth
11.2 cm
Height
5.4 cm
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
