Product Description
Hanwha Techwin WiseNet X XND-8081VZ - network surveillance camera
Device Type
Network surveillance camera - pan / tilt / zoom - indoor - vandal-proof
Audio
Yes: two-way audio capability
Dimensions (WxDxH)
16 cm x 16 cm x 12.5 cm
Weight
1.45 kg
Colour
White, RAL 9003
Connectivity Technology
Wired
Camera
Colour - Day&Night
Optical Zoom
2.6 x
Max Resolution
2560 x 1920
Frame Rate (max)
30 frames per second
Motion Detection
Yes
Optical Sensor Type
CMOS - 1/1.8" - 6 MP
Minimum Illumination
0.07 lux - colour - F1.2 - shutter 1/30 sec ¦ 0.007 lux - B&W - F1.2 - shutter 1/30 sec
Focal Length Control
Motorized zoom
Focal Length
3.6 mm - 9.4 mm
Focus Adjustment
(min distance 50 cm)
Lens Iris
F/1.2-2.4 - auto iris (DC, P-Iris)
Panning Range (degree)
-175 to +175
Tilting Range (degree)
0 to 85
Interfaces
Ethernet 10Base-T/100Base-TX
Voltage
DC 12 V / PoE Class 3
Features
Backlight Compensation (BLC), image flip, image mirror, Wide Dynamic Range (WDR), face detection, Motion Detection Technology, Privacy Mask Function, Digital Image Stabilization (DIS), Lens Distortion Compensation (LDC), tamper-detection, digital PTZ function, shock detection, Variable Bitrate (VBR), Constant Bitrate (CBR), Audio Detection, Multicast Streaming, Defog, Smart Codec, auto gain control, auto white balance, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, loitering detection, people counting, Heat Map, Samsung Super Noise Reduction (SSNRV), WiseStream II support, IP address filtering, Hallway View, fog detection, Handover, Virtual Line detection, Directional Detection
Environmental Parameters (operating)
-25 °C - 60 °C; 0 - 90% relative humidity
