Discover the Dataram EC500, a solid state drive designed for durability and high performance. With a shock acceleration tolerance of up to 1500 g for non-operating conditions and operational vibration frequency range of 20-2000 Hz, it's built to last under extreme conditions. The drive boasts an impressive internal data rate of 560 MBps read and 495 MBps write, along with 4KB random reads and writes of 96000 IOPS and 79000 IOPS respectively, making it ideal for data-intensive applications.¦Security is paramount, and the EC500 doesn't disappoint with its 256-bit AES encryption algorithm, ensuring your data is protected. A capacity of 240 GB, coupled with features like DRAM cache, Device Sleep support, and TRIM support, makes it a reliable choice for both personal and professional use. Its compliance with S.M.A.R.T. standards and a drive writes per day (DWPD) of 1.42 further attest to its durability and reliability, making it an excellent investment for those seeking a robust storage solution.
DATARAM

Dataram EC500 - SSD - 240 GB - internal - 2.5" - SATA 6Gb/s - 256-bit AES
SKU
1TCPTMEM-023330
Manufacture#: EC500S5AT/240G
£93.27
£111.92 inc VAT
Order by 15:00 and receive your order on Friday 28 Feb
Product details
- SSD
- 240 GB
- internal
- 2.5"

Payment options available at checkout
Overview
Specification
Product Description
Dataram EC500 - SSD - 240 GB - SATA 6Gb/s
Type
Solid state drive - internal
Capacity
240 GB
Encryption Algorithm
256-bit AES
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
2.5"
Interface
SATA 6Gb/s
Features
TRIM support, End-to-end data protection, thermal sensor, Global Wear Leveling, flash bad-block management, Flash Translation Layer (FTL), Device Sleep support, DRAM cache, S.M.A.R.T.
Dimensions (WxDxH)
69.85 mm x 100 mm x 6.9 mm
Weight
63 g
Manufacturer Warranty
5-year warranty
Extended Specification
General
Device Type
Solid state drive - internal
Capacity
240 GB
Encryption Algorithm
256-bit AES
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
2.5"
Interface
SATA 6Gb/s
Features
TRIM support, End-to-end data protection, thermal sensor, Global Wear Leveling, flash bad-block management, Flash Translation Layer (FTL), Device Sleep support, DRAM cache, S.M.A.R.T.
Width
69.85 mm
Depth
100 mm
Height
6.9 mm
Weight
63 g
Performance
Drive Writes Per Day (DWPD)
1.42
Internal Data Rate
560 MBps (read) / 495 MBps (write)
4KB Random Read
96000 IOPS
4KB Random Write
79000 IOPS
Reliability
MTBF
3,000,000 hours
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s
Compatible Bay
2.5"
Miscellaneous
Compliant Standards
RoHS, FCC, UL
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Min Storage Temperature
-40 °C
Max Storage Temperature
100 °C
Shock Tolerance (operating)
50 g @ 11 ms half-sine pulse
Shock Tolerance (non-operating)
1500 g @ 0.5 ms half-sine
Vibration Tolerance (operating)
7.69 g @ 20-2000 Hz
Vibration Tolerance (non-operating)
4.02 g @ 15-2000 Hz
